Parameter
| model | TB-1900 |
| stroke | 1800*520*520 |
| Workbench size | 1900*500 |
| T-shaped groove | 3*18*125 |
| Maximum load capacity of workbench (kg) | 500 |
| Distance from workbench to spindle end face | 100-620 |
| Distance from spindle center to column rail surface | |
| principal axis | |
| Taper | BT40 |
| Speed | Directly connected to 12000 |
| Motor power MTSUBISHI | 11/15/18.5 |
| Single machine power * Fanuc | 11/15/18.5 |
| Triaxial | |
| Motor power MITSUBISHI | 3.0/3.0/3.0 |
| Single machine power * Fanuc | 3.0/3.0/3.0 |
| Guide rail specifications | X-axis roller guide 35 Y-axis roller guide 30 Z-axis roller guide 35 |
| Screw specifications | 4016*3616*3616 |
| G01 feed rate | 1-10000 |
| G00 fast moving speed | 48/48/48 |
| Positioning accuracy | ±0.005/300 |
| Repetitive positioning accuracy | ±0.003/300 |
| Tool magazine | |
| Robot tool library | 24 |
| Tool change time | 1.3-1.55 |
| Maximum tool length | 300 |
| Maximum tool diameter (full tool) | 80 |
| Maximum tool diameter (adjacent to empty tool) | 160 |
| Maximum tool weight (kg) | 8 |
| Other | |
| Machine weight | 5500 |
| Electricity demand | 30 |
| Pressure demand | 6 |
| Appearance dimensions |
